Piezo Ceramic Capacitors

Piezo Ceramic Capacitors
Piezo Ceramic Capacitors
Product Code : C.E-04
Brand Name : CEDICOM ELECTRONICS
Price And Quantity
  • Minimum Order Quantity
  • 500
  • Unit of Measure
  • Piece/Pieces
Product Description

Piezo Ceramic Ringers

To meet variegated requests of our regarded customers, we as a prime manufacturer, supplier, trader are occupied with offering an elite array of Piezo Ceramic Ringers. For assembling this ringer, our qualified experts use quality tried crude material with the assistance of imaginative technique according to the set business principles and standards. This ringer is altogether checked against various parameters of value to wipe out any sort of defect. Our array of Piezo Ceramic Ringers is all around acclaimed for features, such as, absolutely designed, sturdiness, low support array.

Specifications :

Model No

Tone

Sound Level

Oscillation
Frequency

Power
Consumption

Operating
Voltage

Operating
Temperature

CC 27

Continuous

Minimum 90 dB at 30 cm/spl

4KHz +500 Hz

Maximum 15mA

3 to 24 VDC

-25oC to 60oC

CL 27

Continuous

Minimum 90 dB at 30 cm/spl

4KHz +500Hz

Maximum 15mA

3to 28 VDC

-25oC to 60oC

CM 27

Musical

Minimum 90 dB at 30 cm/spl

Not Applicable

Maximum 15mA

6 to 24 VDC

-25oC to 60oC

CI 27

Intermittent

Minimum 90 dB at 30 cm/spl

4KHz +500 Hz

Maximum 15mA

6to 24 VDC

-25oC to 60oC

CE 27

Continuous

Minimum 85 dB

4 KHz Frequency

Maximum 10mA

3 to 24 VDC

-25oC to 60oC

CC 20

Continuous

Minimum 90 dB at 30 cm/spl

4KHz +-500 Hz

Maximum 15mA

3 to 24 VDC

-25oC to 60oC

CI 20

Intermittent

Minimum 85 dB at 30 cm/spl

4KHz +-500 Hz

Maximum 15mA

3 to 24 VDC

-25oC to 60oC

CP 20

Continuous

Minimum 85 dB at 30 cm/spl

Not Applicable

Maximum 15mA

12v-P-p

-25oC to 60oC

CE 20

Continuous

Minimum 85 dB at 30 cm/spl

4KHz +-500 Hz

Maximum 15mA

3 to 24 VDC

-25oC to 60oC

CC 1212A

Continuous

Minimum 85 dB at 10 cm/spl

2.3KHz +-03KHz

12VDC

8 to - 15 VDC

-25oC to 60oC

CC 1212FA

Continuous

Minimum 85 dB at 10 cm/spl

2.3KHz +-03KHz

12VDC

8 to - 15 VDC

-25oC to 60oC

CC 1206A

Continuous

Minimum 85 dB at 10 cm/spl

2.3KHz +-03KHz

6VDC

4 to - 7 VDC

-25oC to 60oC

CC 1206FA

Continuous

Minimum 85 dB at 10 cm/spl

2.3KHz +-03KHz

6VDC

4 to - 7VDC

-25oC to 60oC

CC 1203A

Continuous

Minimum 85 dB at 10 cm/spl

2.3KHz +-03KHz

3VDC

2 to - 5 VDC

-25oC to 60oC

CC 1203FA

Continuous

Minimum 85 dB at 10 cm/spl

2.3KHz +-03KHz

3VDC

2 to - 5 VDC

-25oC to 60oC

CC 1201A

Continuous

Minimum 85 dB at 10 cm/spl

2.3KHz +-03KHz

1.5VDC

1.2 to -3 VDC

-25oC to 60oC

CMT 12

Continuous

Minimum 85 dB at 10 cm/spl

2.3K2048Hz

5VP-P

3V to 5 VP-P

-25oC to 60oC

CC 14

Continuous

Minimum 80 dB at 10 cm/spl

2.5K ±0.5

12VDC

9V - 12V

-25oC to 60oC


Model No

Tone

Sound Level

Oscillation
Frequency

Power
Consumption

Operating
Voltage

Operating
Temperature

CAC 27

Continuous

Minimum 100 dB at 30 cm/spl

4 KHz +500Hz

Maximum 22 MA

140V-230VAC

-25oC to 60oC


Model No

Tone

Sound Level

Oscillation
Frequency

Power
Consumption

Operating
Voltage

Operating
Temperature

CAC 27

Continuous

Minimum 100 dB at 30 cm/spl

4 KHz +500Hz

Maximum 22 MA

140V-230VAC

-25oC to 60oC

Product Code & Specifications :

Model No.

Capacitance

Sound Level

Resonant Frequency

Input Voltage

Tone

Operating Temperature

CR 41

100NF + 30%

Minimum 90 dB at 30 cm/spl

1 KHz + 0.5 KHz

30 VP-P

Ringing

-20oC to 70oC

CR 31

75NF + 30%

Minimum 85 dB at 30 cm/spl

1.5 KHz + 0.5 KHz

30 VP-P

Ringing

-20oC to 70oC

CR 27

70NF + 30%

Minimum 85 dB at 30 cm/spl

2.0 KHz + 0.5 KHz

30 VP-P

Ringing

-20oC to 70oC
